Chicago Pneumatic CP7406 Air Angle Die Grinder, 1/4" Collet, 0.34 HP,

• Chicago Pneumatic CP7406 is a compact right angle pneumatic die grinder for professional maintenance and body shop work. It features a 1/4 Inch collet, a free speed of 23000 RPM, and a 0.34 HP motor, pairing a rear exhaust and a spindle lock for quick burr changes and precise control.
• Features:
  • 1/4 Inch collet fits common burrs and accessories for broad application coverage.
  • 0.34 HP motor with 23000 RPM free speed delivers fast material removal and fine finishing.
  • Spindle lock enables one wrench burr changes to reduce setup time.
  • Right angle head and compact 6.4 Inch length improve access in tight spaces.
  • Safety lever throttle and rear exhaust support controlled operation and user comfort.
• Specifications:
  • Manufacturer: Chicago Pneumatic
  • Part Number: CP7406
  • Product Type / Function: Right angle pneumatic die grinder
  • Max Power: 0.34 HP / 250 W
  • Free Speed: 23000 RPM
  • Collet Size: 1/4 Inch
  • Angle Type: 90 Degree
  • Length: 6.42 Inch
  • Weight: 1.32 lb
  • Air Inlet: 1/4 Inch NPT
  • Air Consumption at Load: 2.1 cfm
  • Minimum Hose Diameter: 3/8 Inch
  • Exhaust: Rear
  • Starting System: Safety lever
  • System Compatibility or Application: For grinding, deburring, and surface prep using 1/4 Inch shank accessories on automotive and industrial tasks
• The CP7406 air angle die grinder can also be referred to as air angle die grinder, 1/4 Inch pneumatic die grinder, right angle die grinder, CP7406 grinder, and Chicago Pneumatic die grinder.

Chicago Pneumatic designs and manufactures professional pneumatic tools and compressed air solutions for maintenance, body shop, and industrial applications.

Q: What air supply do I need for CP7406?
A: Provide clean, lubricated air at about 2.1 cfm under load through a 3/8 Inch hose and a 1/4 Inch NPT inlet, with typical shop pressure set around 90 psi per the specification.

Q: Can I change burrs without two wrenches?
A: Yes. The spindle lock allows one wrench burr changes for faster setup.

Q: What accessories fit this grinder?
A: Use 1/4 Inch shank burrs and grinding accessories rated for at least 23000 RPM and follow the accessory manufacturer’s guidelines.
