Chicago Pneumatic CP7782-6 1" Dr. Impact Wrench w/ 6" Extended Anvil

Designed for tire changing applications, this 1" impact wrench with its high torque of 1,920 ft.lbs is highly recommended. The pinless closed reinforced rocking dog impact mechanism and metal housing offer high durability. The CP7782 series includes 3 models: 1" short anvil, 1" long anvil (6" anvil) and 1" long anvil (6" anvil) with spline retainer.

Benefits1,920 ft.lbs ( 2,600 Nm) of max torque in reverse position for high productivityMetal housing and pinless closed reinforced rocking dog impact mechanism for high durabilityPower control regulators at the rear of the unit with 3 reverse and 3 forward positionsIntegrated protective cover on the clutch housing protects both applications & toolLow vibration for improved comfort

Technical Specifications

Design & FunctionsStarting systemTriggerSide handleYesMax dynamic air working pressure91 psiHandle typeD-handleMax torque reverse1920 ft.lbClutch housingSteelSound Pressure100 dB(A)Vibration (m/s²)7.8Length (L)20.47 inMin working torque fwd369 ft.lbfWeight25.5 lbImpact mecanismPinless rocking dogMax working torque fwd1480 ft.lb
